Highlight:
1.5V Alkaline C Cell Batteries LR14
, 1.5V Alkaline C Cell Batteries
, Industrial Alkaline C Batteries LR14
Industrial 1.5V Alkaline C Cell Batteries LR14 Non Rechargeable Cell Battery
Alkaline C Batteries C Cell 1.5 Volt Battery LR14 battery non rechargeable cell
LR14 Battery is a alkaline batteries in size C 1.5V voltage and non-rechargeable battery LR14
This product is available in Transfer Multisort Elektronik.
C Battery with Long-lasting Power, All-Purpose Alkaline C Battery for Household and Office Devices
alkaline batteries deliver the lasting power and performance you can count on for electronic devices throughout the home or on-the-go
As a general-purpose battery, the LR14 C alkaline battery is made to power everyday devices throughout the home, like toys, remote controls, flashlights, clocks and radios, portable electronics, and more
Our alkaline batteries is available in Double A (AA), Triple A (AAA), C, D, and 9V sizes..
LR14 C cell is a disposable abttery in cylinder shape that provide 1.5Volt power
Chemical system:Zn-MnO2(KOH), without Hg&Cr
Nominal Voltage:1.5V
Designation : IEC:LR14 ANSI: C JIS:AM-2 Others: E93
Battery type LR14 C 1.5V
Diamter 24.9~26.2 mm
Height 48.6~50.0 mm
Weight 0.0682 kg
Capacity 7500mah Testing condition 10mA, 24h/d, 20°c,e.v.=0.8V
Alkaline Cylindrical Battery 0% Mercury Alkaline Cylindrical Battery Series LR14 battery 1.5 volt batteries
Model: LR14
Size: C
Voltage: 1.5 V
LR14 Signs
The following signs are on the battery body:
1. Model:LR14/C
2. Manufacturer and brand
3. Battery Poles:“+”and“-”
4. Expiry date or manufacturing date
Data sheet for LR14 batteries C battery 1.5 volt
| Model |
LR14 C |
| Diameter |
24.9-26.2 |
| Height |
48.6-50.0 |
| Norminal voltage |
1.5 volt
|
| Test condition/discharge time |
3.9Ω, 24h/d, 0.8V / 20H |
| 6.8Ω, 1h/d, 0.9V / 39H |
| Storage time |
more than 5 years |
| LOGO |
OEM |
| Package |
Welcome OEM customer logo too |
| Battery pack |
any combinations welcome customized |
Hot sale Alkaline batteries from Hynna
Alkaline Primary cell
| Model |
Diameter mm |
Height mm |
Norminal Voltage V |
Test condition |
Discharge |
| 23A |
9.9-10.2 |
28.1-28.7 |
1.5 |
20KΩ, 24h/d, 7.2V |
98h |
| 27A |
7.65-7.85 |
27.7-28.3 |
1.5 |
20KΩ, 24h/d, 7.2V |
36h |
| LR03/AAA/七号 |
9.5-10.5 |
43.3-44.5 |
1.5 |
10Ω, 24h/d, 0.9V |
8h |
| 3.9Ω, 24h/d, 0.9V |
2.5h |
| LR6/AA/五号 |
13.5-14.5 |
49.2-50.5 |
1.5 |
10Ω, 24h/d, 0.9V |
19.1h |
| 3.9Ω, 24h/d, 0.9V |
6.4h |
| LR14/C/二号 |
24.9-26.2 |
48.6-50.0 |
1.5 |
3.9Ω, 24h/d, 0.8V |
20h |
| 6.8Ω, 1h/d, 0.9V |
39h |
| LR20/D/大号 |
32.3-34.2 |
59.5-61.5 |
1.5 |
22Ω, 24h/d, 0.8V |
19h |
| 3.9Ω, 1h/d, 0.9V |
42h |
| 6LR61/9V |
26.5*17.5*48.5 |
9 |
180Ω, 24h/d, 4.8V |
800min |
| 270Ω, 1h/d, 5.4V |
1150min |
Rechargeable Alkaline batteries
| Model |
Diameter |
Height |
Norminal Voltage |
Test condition |
Discharge |
Cycle life Times |
| HR03/AAA/7号 |
9.5-10.5 |
43.3-44.5 |
1.5 |
100mA, 24h/d, 0.9V |
900mAh |
50-200 times |
| 300mA, 24h/d, 0.9V |
600mAh |
50-200 times |
| HR6/AA/5号 |
13.5-14.5 |
49.2-50.5 |
1.5 |
100mA, 24h/d, 0.9V |
1800mAh |
50-200 times |
| 300mA, 24h/d, 0.9V |
1500mAh |
50-200 times |
Alkalline batteries Cautions for using
1. This battery can’t be charged,leakage and explosion may happen when charging.
2. Make sure the battery is in correct position as + and -.
3. Short-circuit,heating,disposing of into fire or disassembling of battery is prohibited.
4. Battery can not be forced discharged, which leads to excess gassing and may result in bulging,leakage and de-crimping of cap.
5. New batteries and used ones can not be used at the same time. It is recommended to use the same brand when replacing batteries.
6. The battery should be taken out from the device which will not be used for a long time.
7. Exhausted battery should be taken out from the device.
8. Welding batteries are prohibited or it will cause damage.
9. The batteries should be kept from children,if swallowed,contact a doctor immediately.
